TPS-025MD-CA1N-00-T (20031638-00)
Differential Pressure Sensor
Die minimale Bestellmenge beträgt 1 Stk.!
10,00 €
The TPS (TE Connectivity Pressure Sensors) are low pressure MEMS sensors offering state-of-the-art pressure transducer technology and CMOS mixed signal processing technology to produce either an analog and/or digital output fully conditioned, multi-order pressure and temperature compensated. This series provides JEDEC standard SOIC-16 package with dual vertical, dual horizontal or Manifold porting options. It is available in gage, differential and asymmetric differential configurations. With the dual porting, a reference measurement is possible to minimize errors due to changes in ambient pressure.
Combining the pressure sensor with a signal-conditioning ASIC in a single package simplifies the use of advanced silicon micro-machined pressure sensors. The pressure sensor can be mounted directly on a standard printed circuit board and a high level, calibrated pressure signal can be acquired from the digital interface. This eliminates the need for additional circuitry, such as a compensation network or microcontroller containing a custom correction algorithm.
The TPS products are shipped in tape & reel.
Key Specifications
- Pressure Range: -25mBar to +25mBar
- Pressure Type: Differential
- Package Type and Porting: SOIC-16 w/ dual vertical porting
- Pressure total error band : ± 1% FS (digital & analog)
- Pressure calibrated and temperature compensated output
- Compensated temperature range: -20 to 85oC
- I2C/ I3C digital and analog output interface available
